Key features
- 730 W
- 23.50%
- N-type TOPCon bifacial (80%)
- Voc 49.36 V
- Isc 18.81 A
- Vmp 41.11 V
- Imp 17.76 A
- 2384x1303x33 mm
- 37.5 kg
- 1500 V
- 12 yr product / 30 yr power
Options and specifications
| Option | Model code | Specifications | How to buy |
|---|---|---|---|
| Single panel | JKM730N-66HL5-BDV | 730 W; 23.50%; N-type TOPCon bifacial (80%); Voc 49.36 V; Isc 18.81 A; Vmp 41.11 V; Imp 17.76 A; 2384x1303x33 mm; 37.5 kg; 1500 V; 12 yr product / 30 yr power | Buy online |
| Pallet of 33 | JKM730N-66HL5-BDV x33 | 33 panels = 24.09 kWp per pallet | Pay after our call |
Works with
All inverters: check MPPT current (Isc 18.81 A)
Datasheet
Download the official datasheet (PDF)
How to buy
Add to cart and pay online by card or bank transfer. We confirm the delivery cost before you pay.
Installation by e-Phaim engineers
Add installation and we wire your home, office or facility in two layers. Critical loads like lighting, computers, servers and security stay on. Heavy loads like air conditioners switch off on their own when the sun is weak and there is no grid, so your essentials keep running.
Delivery and warranty
Delivery anywhere in Nigeria, with the cost worked out for each order. Pickup from our Abuja, Lagos or Maiduguri offices. Maker warranty on every item; returns only if faulty on arrival.
